[IL Single Point Sensor] IL-150~IL-2t Mettler Toledo Mettler Toledo Weighing Sensor

　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　　

【Guangzhou Zhongxin Automation Technology Co., Ltd】Professional supply of Swiss Mettler Toledo Mettler Toledo IL series weighing sensors, 【 IL single point sensor 】 IL-150~IL-2t Mettler Toledo Mettler Toledo weighing sensors guarantee fast delivery time, 100% original and authentic products, striving to become the first brand of sensor sales in China. Swiss Mettler Toledo IL seriesThe weighing sensorRelated model: IL-150kg, IL-250kg,IL-500kg,IL-1000kg,IL-2000KG。

Mettler Toledo IL Series Product Introduction

English name: METTLER TOLEDO weighing sensor
Chinese name:Mettler Toledo weighing sensor
Product features:
Box type weighing sensor
Alloy steel material, good stability, and product safety
Protection level IP67
Range options: 150kg, 250kg, 500kg, 1000kg, 2000kg
Applied to packaging scales, platform scales, and other small and medium-sized weighing equipment

Mettler Toledo IL Series Installation Dimensions

　

Mettler Toledo IL series technical specifications

　

Mettler Toledo IL series precautions

1. Pay attention to ensuring that the sensor is loaded vertically during use;
2. Avoid long-term over range use and avoid overloading during use;
3. During transportation, be careful not to break the IL weighing sensor wires due to compression

Expand reading

Brand Introduction
METTLER TOLEDO, as a leading global manufacturer of precision instruments and scales, has maintained technological and market leadership throughout its century long development history. Nowadays, the solutions provided by Mettler Toledo cover various processes and links in the laboratory, industrial, and retail (commercial) industries. From high-precision microanalysis to weighing applications of over a thousand tons, Mettler Toledo's unified team, global service network, and perfect solutions help global users improve efficiency, create value, and easily cope with various challenges.
　
The origin of box type weighing sensors
In the discussion of the first International Industrial Weighting and Force-measuring Exhibition in 1979, a new term emerged in the terminology of sensors: "single point" force sensing. The latest generation of retail scales did not include any auxiliary flexures supporting the upper weighing software platform, which was rigidly fixed to the central sensor. The design of this type of box type force sensor is based on the parallelogram principle, but an additional center cross beam should be provided for the strain gauge to complete the task of measuring beams and deflection components in the top and bottom parts of the parallelogram. Its advantage is that the strain gauge moves away from the position caused by eccentric loading, which leads to twisting effects, while increasing the rigidity of the structure. This type of force sensor is subjected to eccentric loading tests in the manufacturing plant. Apply 1/3 of the sensor's maximum load in different directions within a radius of 200 millimeters. Each sensor must operate within ± 1/3000 of the center reading value, which is a typical design. Another noteworthy new news in the field of force sensors is the promotion and application of the principle of gyroscopes. The gyroscopic force measurement system utilizes the proprietary characteristics of the tourbillon, making it a precise, linear, and reproducible force sensor. After studying the anti lag, anti drift, and anti temperature effects of this force sensor, the gyroscopic force measurement system can transmit direct digital signals to the display unit with high anti-interference performance. These characteristics make it completely independent of harsh environmental conditions. The rotor of the gyroscope rotates at a constant speed, and the horizontal axis of the rotor is installed in a universal support. There is a movable joint hanging an external universal support, which also supports one end of the movable lever below the tourbillon.
　
The above is the detailed information of the IL Single Point Sensor IL-150~IL-2t Mettler Toledo Mettler Toledo weighing sensor. If you have any questions about the price, delivery time, model, or inventory of the IL Single Point Sensor IL-150~IL-2t Mettler Toledo Mettler Toledo weighing sensor, please feel free to call us18520271262 Chen GongGet the latest price details for the IL single point sensor IL-150~IL-2t-Meter Toledo weighing sensor.
