Guangzhou Zhongxin Automation Technology Co., Ltd】Professional supply of T12HT/500kNm~T12HT/1.5MNm
German HBM torque sensorThe German HBM-T12HT torque sensor guarantees fast delivery time, 100% original and genuine products, and strives to become the top brand of sensor sales in China. The German HBM-T12HT torque sensor is one of our company's key advantageous products, with an absolute competitive price. It is available in stock, original, authentic, and reliable! Ensure satisfactory price and quality!
We solemnly promise:“Any unconditional return or exchange of goods with quality issues within three months, full refund of payment, and no charge”. Warranty1Year, maintenance at any time!
Product Introduction:
German HBM torque sensor T12HT series related models: T12HT/500kNm, T12HT/800kNm, T12HT/1.5MNm.
T12HT torque sensor, suitable for measuring extremely high torque up to 1.5 MN · m
The T12HT torque sensor is specifically designed for high torque applications, with high precision and significantly improved productivity and efficiency. It adopts wireless power supply, wireless signal transmission technology, and has advantages such as maintenance free. The high bandwidth of internal circuits can bring you faster measurement results.
The T12HT torque sensor is an ideal choice for offshore and onshore wind power generation, used in the energy industry and ship engine test benches, and can also be used for calibration services.
The rated torque range ranges from 500 kN · m to 1.5 MN · m, with a maximum speed of 1000 rpm. In addition, an integrated magnetic speed measurement system is also provided.
HBM accuracy level: 0.1
Bandwidth: 6 kHz (-3 dB)
Rated range: 500 kN · m; 800 kN · m; 1.5 MN · m
High precision, excellent linearity, with a lag of only 0.05%
Extremely high temperature stability, TC0 is 0.05%/10K
Bandwidth up to 6 kHz
Rated torque: 500 kN · m; 800 kN · m; 1.5 MN · m
Rated speed: 1000 rpm
High stability, even for environments with drastic temperature changes
Internal calibration, tracing back to German national standards
100% maintenance free, friction free, without bearings or slip rings
Long service life
Expand reading
Torque sensors and torque sensors
As the world's first manufacturer of digital torque sensors, HBM's products include torque sensors (torque sensors, torque sensors), non rotating torque sensors (torque sensors) for measuring reaction forces, as well as various couplings and measuring instruments for torque sensors (torque sensors). HBM has patented technology for slip ring and non-contact signal transmission, with a rated measurement range from 0.1 N • m to 2 MN • m and a maximum rated speed of 40000 rpm.
The HBM torque sensor has always been renowned in the industry. Since 1958, HBM torque sensors (torque sensors, torque sensors) have been an industry standard widely used in engine and component testing benches, production monitoring, and laboratory torque calibration.
The first calibration laboratory of DKD (German calibration service agency) was established in HBM in 1977. On July 13, 1990, HBM was awarded torque calibration by DKD. For many years, HBM has been the only laboratory in Germany that can provide torque calibration services and is responsible for developing national standards
T12, T40FM, T40, and T40B are the new generation digital torque sensors. It adopts a special analog-to-digital conversion method, which not only has error recognition function and is not sensitive to electromagnetic environment, but also has higher sampling rate and accuracy.
The above is T12HT/500kNm~T12HT/1.5MNmGerman HBMDetailed information on torque sensors. If you have any questions about the price, delivery time, model, or inventory of T12HT/500kNm~T12HT/1.5MNm German HBM torque sensors, please feel free to call us18520271262 Chen GongObtain the latest price details of T12HT/500kNm~T12HT/1.5MNm German HBM torque sensors.
