TECHICAL PARAMETER丨4Wires Exc+(Red);Exc-(Black);Sig+(Green);Sig-(White) | |||
额定载荷: | 10kg~2000kg | 输入阻抗: | 387 Ω±20Ω |
精度等级: | 0.5% | 输出阻抗: | 350 Ω±5Ω |
灵敏度: | 1.0~1.5mV/V±1% | 温度补偿范围: | -10℃ to+30℃ |
非线性: | ±0.3% of rated output | 工作温度范围: | -10℃ to+70℃ |
滞后误差: | ±0.1% of rated output | 安全负载: | 150% |
蠕变(30min): | ±0.05% of rated output | 推荐激励电压 | 5V DC/AC |
零点温度影响: | ≤0.05% of rated output/℃ | 最大工作电压: | 10V DC/AC |
灵敏度温度影响: | ≤0.05% of applied output/℃ | 密封等级: | IP67 |
绝缘电阻: | ≥5000MΩ(50V DC) | 电缆: | 3m (可定制) |
